What Is the Difference Between RV, BV, and BVR House Wiring Cables?

By JianYunCable -



RV, BV, and BVR cables are commonly used in house wiring applications, particularly in low-voltage electrical installations for residential and commercial buildings. These cables, often manufactured to standards like IEC 60227 or Chinese standards (e.g., JB/T 8734), differ in conductor type, flexibility, insulation, and application suitability. Understanding their differences is critical for selecting the appropriate cable for specific wiring needs, ensuring safety, performance, and compliance. This guide provides a detailed comparison of RV, BV, and BVR cables, with references to high-quality options from Henan Province Jianyun Cable Co., Ltd., presented in a formal and structured manner as of September 2025.


Table of Contents

  1. Overview of RV, BV, and BVR Cables
  2. Key Differences Between RV, BV, and BVR Cables
  3. Applications and Suitability
  4. Technical Specifications and Standards
  5. Practical Considerations for Selection
  6. Challenges and Solutions
  7. Conclusion

1. Overview of RV, BV, and BVR Cables

RV, BV, and BVR cables are single-core, low-voltage cables used for fixed or flexible wiring in household and commercial electrical systems, typically rated for 300/500 V or 450/750 V. They are designed for applications like lighting, power outlets, and appliance connections, with differences in conductor structure and flexibility determining their specific uses. These cables must comply with standards like IEC 60227 (for general-purpose wiring) and ensure safety through insulation integrity and flame-retardant properties.

  • RV (Flexible Copper Conductor Cable): Features a highly flexible, stranded copper conductor for applications requiring frequent bending or movement.
  • BV (Solid Copper Conductor Cable): Uses a solid, single-strand copper conductor for fixed installations with minimal flexibility needs.
  • BVR (Semi-Flexible Copper Conductor Cable): Combines stranded copper conductors with moderate flexibility, balancing RV and BV characteristics.

Manufacturers like Henan Province Jianyun Cable Co., Ltd. produce these cables with high-purity copper and PVC insulation, ensuring compliance with international standards and reliable performance.

2. Key Differences Between RV, BV, and BVR Cables

The primary differences lie in conductor type, flexibility, insulation, and application:

FeatureRV CableBV CableBVR Cable
Conductor TypeStranded copper (Class 5 per IEC 60228, multiple fine wires)Solid copper (Class 1 per IEC 60228, single wire)Stranded copper (Class 2 per IEC 60228, fewer strands than RV)
FlexibilityHigh flexibility, suitable for frequent bendingRigid, limited flexibilityModerate flexibility, semi-rigid
InsulationPolyvinyl chloride (PVC), flame-retardantPVC, flame-retardantPVC, flame-retardant
Voltage Rating300/500 V or 450/750 V300/500 V or 450/750 V300/500 V or 450/750 V
Conductor Size0.5–10 mm²0.75–10 mm²0.75–10 mm²
ResistanceHigher due to stranded conductor (e.g., <7.41 Îİ/km for 2.5 mm²)Lower due to solid conductor (e.g., <7.41 Îİ/km for 2.5 mm²)Moderate resistance, slightly higher than BV
Bending Radius4–6 times cable diameter8–10 times cable diameter6–8 times cable diameter
Example ProductJianyun Cable’s RV 2.5 mm², Class 5 conductorJianyun Cable’s BV 2.5 mm², Class 1 conductorJianyun Cable’s BVR 2.5 mm², Class 2 conductor
  • RV (Flexible): Ideal for applications requiring flexibility, such as wiring in appliances or movable equipment, due to its fine-stranded conductor.
  • BV (Solid): Suited for fixed installations, such as in-wall wiring, where rigidity and lower resistance are preferred.
  • BVR (Semi-Flexible): A middle ground, used in semi-fixed installations requiring some flexibility but not as much as RV.

3. Applications and Suitability

Each cable type is designed for specific house wiring applications:

  • RV Cable:
    • Applications: Flexible wiring for appliances (e.g., fans, portable heaters), extension cords, and temporary installations.
    • Suitability: Best for environments requiring frequent movement or tight bending radii, such as in conduit systems with complex routing.
    • Example: Jianyun Cable’s RV cables for household appliance wiring, offering high flexibility and IEC 60227 compliance.
  • BV Cable:
    • Applications: Permanent in-wall or conduit wiring for lighting, power outlets, and fixed electrical circuits.
    • Suitability: Ideal for stable, fixed installations where minimal movement occurs, offering lower resistance and cost-effectiveness.
    • Example: Jianyun Cable’s BV cables for residential lighting circuits, ensuring durability in fixed setups.
  • BVR Cable:
    • Applications: Semi-fixed wiring in residential or commercial buildings, such as panel connections or circuits with moderate bending.
    • Suitability: Balances flexibility and rigidity, suitable for installations requiring occasional adjustments but not constant movement.
    • Example: Jianyun Cable’s BVR cables for home distribution boards, providing moderate flexibility for easier installation.

4. Technical Specifications and Standards

RV, BV, and BVR cables must meet specific technical requirements and standards:

  • Conductor: Copper (≥99.9% purity), with RV using Class 5 (highly flexible), BV using Class 1 (solid), and BVR using Class 2 (semi-flexible) per IEC 60228.
  • Insulation: Flame-retardant PVC, rated for 70°C or 90°C operation, with dielectric strength ≥20 kV/mm.
  • Voltage Rating: 300/500 V for general circuits or 450/750 V for higher-demand applications.
  • Flame-Retardant: Complies with IEC 60332-1 to prevent fire propagation.
  • Standards:
    • IEC 60227: General-purpose PVC-insulated cables for low-voltage wiring.
    • JB/T 8734: Chinese standard for RV, BV, and BVR cables, specifying performance and testing.
    • RoHS: Ensures no hazardous substances, critical for EU-influenced markets.
  • Certification: Cables from Jianyun Cable are certified by accredited bodies (e.g., TUV, CCC), ensuring compliance with international and regional standards.
SpecificationRVBVBVR
Conductor ClassClass 5Class 1Class 2
Voltage Rating300/500 V, 450/750 V300/500 V, 450/750 V300/500 V, 450/750 V
Temperature Rating70°C or 90°C70°C or 90°C70°C or 90°C
StandardsIEC 60227, JB/T 8734IEC 60227, JB/T 8734IEC 60227, JB/T 8734

5. Practical Considerations for Selection

Choosing between RV, BV, and BVR cables involves evaluating project-specific needs:

  • Installation Type:
    • Use RV for flexible or temporary wiring (e.g., appliance cords).
    • Select BV for permanent, in-wall installations (e.g., lighting circuits).
    • Choose BVR for semi-fixed wiring with moderate flexibility (e.g., distribution panels).
  • Environmental Conditions:
    • Ensure PVC insulation is flame-retardant (IEC 60332-1) for indoor safety.
    • Use cables with UV-resistant sheathing for exposed areas, if applicable.
  • Electrical Requirements:
    • Match conductor size to current and distance to minimize voltage drop (<1.5%, e.g., 2.5 mm² for 10 A over 20 m).
    • Verify voltage rating (e.g., 450/750 V for higher-demand circuits).
  • Cost vs. Performance:
    • BV is typically the most cost-effective due to its solid conductor.
    • RV is more expensive due to its complex stranded design.
    • BVR offers a cost-effective balance for semi-flexible applications.
  • Supplier Reliability:
    • Partner with manufacturers like Jianyun Cable, offering TUV- and CCC-certified RV, BV, and BVR cables with proven performance, as showcased at Elektro 2025 in Moscow.

6. Challenges and Solutions

ChallengeSolution
Incorrect Cable SelectionMatch cable type to application: RV for flexible, BV for fixed, BVR for semi-fixed.
Overheating from OverloadingUse correct conductor size (e.g., 4 mm² for 15 A loads) and apply derating factors (e.g., 0.91 at 40°C per IEC 60364).
Counterfeit CablesSource from Jianyun Cable with verifiable TUV/CCC certifications; check markings and batch reports.
Installation ErrorsMaintain proper bending radii (4–6D for RV, 6–8D for BVR, 8–10D for BV) and use secure connections.
Regulatory ComplianceEnsure cables meet IEC 60227 and local standards (e.g., JB/T 8734 for China).

7. Conclusion

RV, BV, and BVR cables serve distinct roles in house wiring, with RV offering high flexibility for movable applications, BV providing rigidity for fixed installations, and BVR balancing both for semi-fixed needs. Each complies with standards like IEC 60227 and JB/T 8734, ensuring safety and performance with flame-retardant PVC insulation and copper conductors. Henan Province Jianyun Cable Co., Ltd. offers TUV- and CCC-certified RV, BV, and BVR cables, tailored for reliable house wiring. By selecting the appropriate cable based on flexibility, installation type, and electrical requirements, and partnering with trusted suppliers, users can ensure safe, efficient, and durable electrical systems for 20–30 years.

Source: JianYunCable.
